Boonton 57006
6 GHz Wideband Peak Power Sensor
Impedance 50 ohm
RF Connector N (M)
Frequency Range (Low Bandwidth) 0.5 - 6 GHz (0.05 - 6 GHz)
Dynamic Range
Peak Power Range** -50 to 20 dBm
CW Power Range -60 to 20 dBm
Int. Trigger Range -40 to 20 dBm
Overload Rating
Pulse 1 W for 1us
Continuous 200 mW
Sensor Response
Fast Risetime (Bandwidth) <7 ns (70 MHz typical)
Slow Risetime (Bandwidth) <10us (350 kHz)
Maximum SWR @ 0 dBm
0.05 - 2 GHz 1.25
** For pulse signal only.
