California Instruments 2003RP
2000VA (675VA per phase) Three-Phase AC Power Source
Use the California Instruments 2003RP three phase, AC power sources for general purpose AC power applications requiring variable voltage and frequency at power levels up to 2000 VA. The wide frequency range of 16 Hz to 5000 Hz, universal input and convenient source of variable utility power, makes the 2003RP ideal for testing domestic, commercial, defense and avionics equipment and applications.
Dual LCD readouts on the California Instruments 2003RP display programmed settings for voltage, current limit and frequency. Dual voltage ranges provide maximum output current at any programmed voltage up to 270V. Easy-to-use controls on the 2003RP include front panel digital rotary encoders that have an analog feel, with the precision and reliability of digital circuits, to set voltage and frequency.
Available transient functions on the California Instruments 2003RP are voltage step, voltage drop, voltage sweep, voltage surge/sag, frequency step, frequency sweep, and frequency surge/sag. A programmable current limit function provides overload protection of the unit under test.
California Instruments 2003RP - Features and Specifications:
- Cost effective solution for three phase AC power requirements
- Ideal for commercial, military and avionics applications with its 16 Hz to 5000 Hz frequency range
- Compact size for convenient usage
- AC power: 675VA (max per phase)
- Peak current low/high: 15A/7.5A
- Voltage low/high: 0-135V/0-270V
- Power factor: 0.7
- High peak current capability for wide variety of non-linear loads
- Optional measurements include TRMS Volt, TRMS current, peak current, crest factor, real power and power factor
- Low 5.25 inch height saves valuable rack space when stacked
You can get the California Instruments 2003RP on lease or rent from TRS-RenTelco with 365-day customer support.
Contact us and request a quote today.
- Configurations
- Resources
- FAQsAI
BASE, OP1
See Configuration Details
-
BASE
Base Model
-
OP1
IEEE-488/RS232 Interface
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Bracket Protection
Qty: 2 -
Cover Kit AC and DC
Qty: 1 -
Shipping Crate Small Streamline Cable Assembly
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
California Instruments 2003RP Spec Sheet
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the California Instruments 2003RP used for?
The California Instruments 2003RP is used for general-purpose AC power applications requiring variable voltage and frequency, ideal for testing domestic, commercial, defense, and avionics equipment.
What is the maximum power output of the California Instruments 2003RP?
It has a maximum power output of 2000 VA, with each phase capable of 675 VA.
What frequency range does the California Instruments 2003RP support?
The frequency range supported is from 16 Hz to 5000 Hz, making it versatile for various applications.
What display features does the California Instruments 2003RP have?
It features dual LCD readouts displaying programmed settings for voltage, current limit, and frequency.
What are the voltage ranges of the California Instruments 2003RP?
The device has dual voltage ranges of 0-135V and 0-270V, providing maximum output current at any programmed voltage.
What transient functions does the California Instruments 2003RP include?
It includes voltage step, voltage drop, voltage sweep, voltage surge/sag, frequency step, frequency sweep, and frequency surge/sag.
What type of controls does the California Instruments 2003RP use?
The controls include front panel digital rotary encoders that provide an analog feel with the precision and reliability of digital circuits.
What is the power factor of the California Instruments 2003RP?
The power factor is 0.7, which is ideal for a wide variety of non-linear loads.
What optional measurements are available with the California Instruments 2003RP?
Optional measurements include TRMS Volt, TRMS current, peak current, crest factor, real power, and power factor.
What rental and leasing options are available for the California Instruments 2003RP?
TRS-RenTelco offers flexible rental, lease, and purchase options to meet various testing needs and budgets.
