Keysight Technologies 16862A
68 channel, 12.5 GHz timing zoom, 350 MHz Logic Analyzer,
Rent or Lease
Keysight (Formerly Agilent) 16862A is the industry's highest-performance portable logic analyzer. The Keysight 16862A provides you the best insight with deep memory timing capture to help you solve your toughest digital debug challenges.
Keysight, formerly Agilent 16862A - Key Features and Specifications:
- High-speed state and timing with deep memory - Capture the most system activity (up to 128 Mb) at the highest resolution to identify the root cause of a problem and symptom
- Signal integrity - Quickly identify trouble signal with simultaneous eye diagrams on all channels
- Probing and application support - Customize a system for your specific needs with a comprehensive set of probing options and application-specific software
- Upgradable - Rent the capability you need now, then upgrade as your needs evolve
You can rent or lease the Keysight 16862A at TRS-RenTelco with 24/7 customer support.
The latest test equipment - We are often the first to buy newly introduced test and measurement equipment from top T&M manufacturers. If you are looking for a new equipment model we probably have it in stock and available for rent.
Calibrated equipment - All our test equipment comes with 24/7 customer support, and we have an experienced team of metrologists and technicians that calibrate the Keysight 16862A and other products to stringent standards in our 50 GHz ANSI/NCSL Z540-1 compliant laboratory.
Fast delivery options - We are located on the grounds of DFW Airport with a FedEx pickup time of 10:00 PM. This lets us take orders as late as 8:00 PM daily and have the equipment delivered to you the following morning.
Contact us to learn more or request a quote today.
