Keysight Technologies E5346A
34-ch single-ended Mictor probe, connects to 40-pin LA cable
The Keysight (formerly Agilent) E5346A 34-ch single-ended Mictor connector probe, connects to 40-pin LA cable and provides a convenient and easy way to connect an Keysight (formerly Agilent) logic analyzer to the target logic system. For difficult packages to probe such as BGA and TQFP, the E5346A provides an alternative to directly probing the chip. The E5346A provides a high density connection to route important signals to the logic analyzer through AMP Mictor connectors designed onto the board.
Read More
- Configurations
- Resources
- FAQsAI
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Installation Note
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Keysight Technologies E5346A Spec Sheet
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the Keysight E5346A?
The Keysight E5346A is a 34-channel single-ended Mictor probe that connects to a 40-pin logic analyzer cable for convenient and easy connection to a target logic system.
What unique technology does the E5346A feature?
It uses AMP Mictor connectors for high-density connections, ideal for probing difficult packages like BGA and TQFP.
What are the size and weight specifications of the E5346A?
Specific dimensions are not provided; refer to the Keysight datasheet for detailed specifications.
What is the signal integrity of the E5346A?
The probe maintains high signal integrity with minimal loading on the circuit under test.
How is the E5346A powered?
The probe is powered through the connected logic analyzer, eliminating the need for a separate power source.
What accessories are included with the E5346A?
Standard accessories include data cables and adapters, as specified by the rental agreement.
What applications is the E5346A suitable for?
It is ideal for logic analysis and digital system debugging in R&D and manufacturing environments.
What are the benefits of using the E5346A?
Benefits include easy connection to target systems, high signal integrity, and compatibility with various logic analyzers.
What additional features does the E5346A offer?
The probe provides an alternative to direct chip probing, making it suitable for high-density, complex circuit designs.
How can one rent or lease the Keysight E5346A from TRS-RenTelco?
The E5346A can be rented or leased by requesting a quote through the TRS-RenTelco website.
