Keysight Technologies M8040A-32G
32 GBaud integrated bit error ratio (BER) test solution for physical layer characterization
Rent or Lease • Buy Used From $154,700
Keysight Technologies - M8040A-32G
The Keysight Technologies M8040A-32G is a highly integrated BERT (Bit Error Rate Tester) for physical layer characterization and compliance testing. With support for PAM-4 and NRZ signals and data rates up to 32 GBaud.
The M8040A BERT offers true error analysis and provides repeatable and accurate results optimizing the performance margins of your 400GbE devices. The M8040A can be used for receiver (input) testing for many popular interconnect standards that use PAM-4 and NRZ data formats, such as: 50/100/200 GbE, OIF CEI-56G and CEI-112G, Infiniband-HDR and proprietary interfaces for chip-to-chip, chip-to-module, backplanes, repeaters and active optical cables. Freely defined test points, e.g. jitter frequencies, without the need for pre-calculating pattern. Integrated sources for periodic jitter, random jitter and bounded uncorrelated jitter stress generation.
M8040A-32G Product Highlights
- data rates from 2 to 32 Gbaud PAM4 signal
- built-in de-emphasis, analyzer equalization, and clock recovery
- integrated and calibrated jitter injection: RJ, PJ1, PJ2, SJ, BUJ, and clk / 2 jitter
- two pattern generator channels per module to emulate aggressor lane
- interactive link training and SKP OS filtering for 8 / 16 / 32 GT/s PCI Express®
- algorithmic PRBS, QPRBS, and memory-based patterns, pattern sequencer
- for PAM4, gray coding, FEC encoding, and precoder and error distribution analysis
- all options and modules are upgradeable
- offers true error analysis and provides repeatable and accurate results, optimizing the performance margins of your devicesseamless operation with BERT/scope and arbitrary waveform generators
Keysight Technologies & TRS-RenTelco
TRS-RenTelco is a proud partner of Keysight Technologies and offers a wide range of rental, purchase and leasing solutions designed specifically to meet the evolving needs of the electronic testing industry. Our close relationship with Keysight Technologies allows us to ensure we have the right Data Generators/Analyzers solution for your job.
Renting Data Generators/Analyzers
With TRS-RenTelco renting Data Generators/Analyzers equipment has never been easier. Enjoy same-day shipping, lease, and finance options on our inventory of over 5000 electronic testing equipment rentals. As one of North America’s largest test equipment rental providers, it is our mission to support the endeavors of our clients no matter how big or small with reliable expertise, excellent customer service, accuracy, and speed.
Additional Information
Manufacturer Home Page | Keysight Technologies.
- Configurations
- Resources
- FAQsAI
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0P3, M8045A-801, M8045A-G32, M8046A-0P3, M8046A-A32, M8057A-FG, M8070A-1TP
See Configuration Details
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9536A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801
2 EA - Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8046A-A32
Analyzer, one Channel, Data Rate up to 32 GBaud, NRZ
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8046A-0P3
PAM-4 Decoding up to 32 GBaud
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
-
M8070A-1TP
DUT Control Interface, TransPortable, Perpetual License
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
ESD Mat with Ground Cord Anti-Static
Qty: 1 -
Cable USB-A - USB-MiniB
Qty: 1 -
Chassis AXIe 5-Slot with Integrated System Module
Qty: 1 -
Power Cord Assembly Heavy Duty with Square Plug
Qty: 1 -
CD Product Documentation
Qty: 1 -
Controller Embedded AXIe 8 G Ram 160 SSD 2 GBs
Qty: 1 -
Heel Ground Strap
Qty: 1 -
Rosenberger Cable Discharger and Cable
Qty: 1 -
Bandpass Filter 11.1 GHz - 17.5 GHz
Qty: 1 -
Cable External Clock
Qty: 1 -
Termination Plug Coaxial
Qty: 4 -
USB Drive with Software and Manuals
Qty: 1 -
Case Transit
Qty: 1 -
Remote Head for M8045A
Qty: 1 -
Cable External DUT
Qty: 2 -
Pattern Generator - Clock Module BERT 32 GBd
Qty: 1 -
Analyzer BERT 32 GBd
Qty: 1 -
50 ohm SMA Terminator, male
Qty: 4 -
USB Software I/O Libraries
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G2, M8045A-0G3, M8045A-0G4, M8045A-0G9, M8045A-0P3, M8045A-801, M8045A-G32, M8057A-FG
See Configuration Details
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9537A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G2
Second Channel, Hardware and License (requires Remote Head, e.g. M8057A)
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G9
Forward Error Correction (FEC) Encoding, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801
2 EA - Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
ESD Mat with Ground Cord Anti-Static
Qty: 1 -
Cable USB-A - USB-MiniB
Qty: 1 -
Chassis AXIe 5-Slot with Integrated System Module
Qty: 1 -
Power Cord Assembly Heavy Duty with Square Plug
Qty: 1 -
Heel Ground Strap
Qty: 1 -
Rosenberger Cable Discharger and Cable
Qty: 1 -
Termination Plug Coaxial
Qty: 4 -
Case Transit
Qty: 1 -
Remote Head for M8045A
Qty: 1 -
Cable External DUT
Qty: 2 -
Pattern Generator - Clock Module BERT 32 GBd
Qty: 1 -
Controller Embedded AXIe High Performance
Qty: 1 -
USB Software I/O Libraries
Qty: 1 -
Load Fixed 2.4 mm(m)
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0P3, M8045A-801, M8045A-G32, M8057A-FG
See Configuration Details
-
M8045A-801
2 EA - Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9536A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
ESD Mat with Ground Cord Anti-Static
Qty: 1 -
Cable USB-A - USB-MiniB
Qty: 1 -
Chassis AXIe 5-Slot with Integrated System Module
Qty: 1 -
Power Cord Assembly Heavy Duty with Square Plug
Qty: 1 -
Heel Ground Strap
Qty: 1 -
Rosenberger Cable Discharger and Cable
Qty: 1 -
Termination Plug Coaxial
Qty: 4 -
Case Transit
Qty: 1 -
Remote Head for M8045A
Qty: 1 -
Cable External DUT
Qty: 2 -
Pattern Generator - Clock Module BERT 32 GBd
Qty: 1 -
Controller Embedded AXIe High Performance
Qty: 1 -
USB Software I/O Libraries
Qty: 1 -
Load Fixed 2.4 mm(m)
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0G9, M8045A-0P3, M8045A-801, M8045A-G32, M8057A-FG
See Configuration Details
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9536A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-0G9
Forward Error Correction (FEC) Encoding, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801
2 EA - Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Termination Plug Coaxial
Qty: 4 -
Power Cord Assembly Heavy Duty with Square Plug
Qty: 1 -
Cable USB-A - USB-MiniB
Qty: 1 -
Heel Ground Strap
Qty: 1 -
ESD Mat with Ground Cord Anti-Static
Qty: 1 -
Case Transit
Qty: 1 -
Rosenberger Cable Discharger and Cable
Qty: 1 -
Cable External DUT
Qty: 2 -
Pattern Generator - Clock Module BERT 32 GBd
Qty: 1 -
Remote Head for M8045A
Qty: 1 -
Chassis AXIe 5-Slot with Integrated System Module
Qty: 1 -
Controller Embedded AXIe High Performance
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0G6, M8045A-0P3, M8045A-801, M8045A-G32, M8057A-FG
See Configuration Details
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9536A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-0G6
Reference Clock Multipler, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801
2 EA - Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Termination Plug Coaxial
Qty: 4 -
Power Cord Assembly Heavy Duty with Square Plug
Qty: 1 -
Cable USB-A - USB-MiniB
Qty: 1 -
Heel Ground Strap
Qty: 1 -
ESD Mat with Ground Cord Anti-Static
Qty: 1 -
Case Transit
Qty: 1 -
Rosenberger Cable Discharger and Cable
Qty: 1 -
Cable External DUT
Qty: 2 -
Pattern Generator - Clock Module BERT 32 GBd
Qty: 1 -
Remote Head for M8045A
Qty: 1 -
Chassis AXIe 5-Slot with Integrated System Module
Qty: 1 -
Controller Embedded AXIe High Performance
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0P3, M8045A-801, M8045A-G32, M8057A-FG
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cable External DUT
Qty: 2
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0G9, M8045A-0P3, M8045A-801X2, M8045A-G32, M8057A-FG
See Configuration Details
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9536A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-0G9
Forward Error Correction (FEC) Encoding, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801X2
Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0P3, M8045A-801, M8045A-G32, M8057B-FG
See Configuration Details
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9536A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801
2 EA - Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057B-FG
Remote Head for M8045A Pattern Generator, 1 Channel
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Termination Plug Coaxial
Qty: 4 -
Power Cord Assembly Heavy Duty with Square Plug
Qty: 1 -
Cable USB-A - USB-MiniB
Qty: 1 -
Heel Ground Strap
Qty: 1 -
ESD Mat with Ground Cord Anti-Static
Qty: 1 -
Case Transit
Qty: 1 -
Rosenberger Cable Discharger and Cable
Qty: 1 -
Cable External DUT
Qty: 2 -
Pattern Generator - Clock Module BERT 32 GBd
Qty: 1 -
Chassis AXIe 5-Slot with Integrated System Module
Qty: 1 -
Controller Embedded AXIe High Performance
Qty: 1 -
Remote Head for M8045A
Qty: 1 -
Filler Panel (Dark Color)
Qty: 1 -
USB Software I/O Libraries
Qty: 1 -
Load Fixed 2.4 mm(m)
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0P3, M8045A-0P6, M8045A-801, M8045A-G64, M8046A-0P3, M8046A-A32, M8057A-FG
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cable External DUT
Qty: 2 -
Bandpass Filter 11.1 GHz - 17.5 GHz
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G2, M8045A-0G3, M8045A-0G4, M8045A-0G9, M8045A-0P3, M8045A-801, M8045A-G32, M8057A-FG
See Configuration Details
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9537A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G2
Second Channel, Hardware and License (requires Remote Head, e.g. M8057A)
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-0G9
Forward Error Correction (FEC) Encoding, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801
2 EA - Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Termination Plug Coaxial
Qty: 4 -
Power Cord Assembly Heavy Duty with Square Plug
Qty: 1 -
Cable USB-A - USB-MiniB
Qty: 1 -
Heel Ground Strap
Qty: 1 -
ESD Mat with Ground Cord Anti-Static
Qty: 1 -
Case Transit
Qty: 1 -
Rosenberger Cable Discharger and Cable
Qty: 1 -
Cable External DUT
Qty: 2 -
Pattern Generator - Clock Module BERT 32 GBd
Qty: 1 -
Remote Head for M8045A
Qty: 1 -
Chassis AXIe 5-Slot with Integrated System Module
Qty: 1 -
Controller Embedded AXIe High Performance
Qty: 1 -
USB Software I/O Libraries
Qty: 1 -
Load Fixed 2.4 mm(m)
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0P3, M8045A-801, M8045A-G32, M8057A-FG
See Configuration Details
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9536A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801
2 EA - Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Termination Plug Coaxial
Qty: 4 -
Power Cord Assembly Heavy Duty with Square Plug
Qty: 1 -
Cable USB-A - USB-MiniB
Qty: 1 -
Heel Ground Strap
Qty: 1 -
ESD Mat with Ground Cord Anti-Static
Qty: 1 -
Case Transit
Qty: 1 -
Rosenberger Cable Discharger and Cable
Qty: 1 -
Cable External DUT
Qty: 2 -
Pattern Generator - Clock Module BERT 32 GBd
Qty: 1 -
Remote Head for M8045A
Qty: 1 -
Chassis AXIe 5-Slot with Integrated System Module
Qty: 1 -
Controller Embedded AXIe High Performance
Qty: 1 -
USB Software I/O Libraries
Qty: 1 -
Load Fixed 2.4 mm(m)
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0G9, M8045A-0P3, M8045A-801X2, M8045A-G32, M8057A-FG
See Configuration Details
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9536A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-0G9
Forward Error Correction (FEC) Encoding, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801X2
Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
*This item has already been added to your cart. Check your cart for quantity and availability.
--, M8040A-BU1, M8045A-0G3, M8045A-0G4, M8045A-0G6, M8045A-0P3, M8045A-801, M8045A-G32, M8057A-FG, N5991MM1Y-ADD, N5991MMLY-ADD, N5991MMS5A-1FP, N5991MMUY-ADD, N5991PL4A-1FP, N5991SA3A-1FP, N5991SA3A-ADD
See Configuration Details
-
M8040A-BU1
Bundle consisting of one M9505A 5-slot AXIe Chassis and one M9536A AXIe Embedded PC Controller with 16GB RAM Option
-
M8045A-0G3
Advanced Jitter Sources for Receiver Characterization, Module-wide License
-
M8045A-0G4
De-emphasis, Module-wide License
-
M8045A-0G6
Reference Clock Multipler, Module-wide License
-
M8045A-0P3
PAM-4 Encoding up to 32 GBaud, Module-wide License
-
M8045A-801
2 EA - Short Cable 1.85 mm (m) to 1.85 mm (m), 0.15 m, absolute matching 699 ps +- 1 ps
-
M8045A-G32
Pattern Generator one Channel NRZ, Data Rate up to 32 GBaud (requires Remote Head, e.g. M8057A)
-
M8057A-FG
Remote Head for M8045A Pattern Generator, 1 Channel
-
N5991MM1Y-ADD
MIPI M-PHY integrated BER counter interface
-
N5991MMLY-ADD
MIPI M-PHY loop-back support
-
N5991MMS5A-1FP
M-PHY 5.0 receiver test
-
N5991MMUY-ADD
MIPI M-PHY Unipro support
-
N5991PL4A-1FP
PCI Express Gen 4.o link training suite
-
N5991SA3A-1FP
SAS receiver test
-
N5991SA3A-ADD
SAS Integrated BER Counter interface
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Termination Plug Coaxial
Qty: 4 -
Power Cord Assembly Heavy Duty with Square Plug
Qty: 1 -
Cable USB-A - USB-MiniB
Qty: 1 -
Heel Ground Strap
Qty: 1 -
ESD Mat with Ground Cord Anti-Static
Qty: 1 -
Case Transit
Qty: 1 -
Rosenberger Cable Discharger and Cable
Qty: 1 -
Cable External DUT
Qty: 2 -
Pattern Generator - Clock Module BERT 32 GBd
Qty: 1 -
Remote Head for M8045A
Qty: 1 -
Chassis AXIe 5-Slot with Integrated System Module
Qty: 1 -
Controller Embedded AXIe High Performance
Qty: 1 -
USB Software I/O Libraries
Qty: 1 -
Load Fixed 2.4 mm(m)
Qty: 1 -
SOFTWARE AND MANUALS ON USB (M8070B)
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the Keysight M8040A high-performance BERT designed for?
The Keysight M8040A is a highly integrated bit error rate tester for physical layer characterization and compliance testing of devices operating with symbol rates up to 32 Gbaud and 64 Gbaud. It supports both PAM4 and NRZ signal formats, making it suitable for 400/200 GbE, OIF CEI-56G, OIF CEI-112G, PCI Express 32/16/8 GT/s, Thunderbolt 3, 64G/112G Fibre Channel, and InfiniBand HDR interfaces.
What are the data output specifications of the M8040A pattern generator?
The M8040A pattern generator module M8045A with remote head M8057B delivers symbol rates from 2.025 to 58 Gbaud (with over-programming to 64.8 Gbaud for Option G64). Single-ended amplitude with the M8057B remote head reaches 80 mV to 0.9 Vpp, or 160 mV to 1.8 Vpp differential. Transition times are typically 9 ps (20% to 80%) for symbol rates above 32.4 Gbaud, and 11 ps for rates at or below 32.4 Gbaud.
Does the M8040A support both PAM4 and NRZ signal formats?
Yes, the M8040A supports both PAM4 and NRZ formats, selectable directly from the user interface without reconnecting cables. NRZ operation covers data rates from 2 Gb/s to 64 Gb/s, while PAM4 mode operates at symbol rates from 2.025 to 32 Gbaud (Option 0P3) or up to 64 Gbaud (with additional Option 0P6). At 64 Gbaud PAM4, the effective data rate reaches 128 Gbit/s.
What jitter injection capabilities does the M8040A provide for receiver stress testing?
The M8040A provides built-in and calibrated jitter sources that can be used simultaneously, including random jitter (RJ), two tones of periodic jitter (PJ1 and PJ2), sinusoidal jitter (SJ), bounded uncorrelated jitter (BUJ), clock/2 jitter, and spread-spectrum clocking (SSC). The pattern generator also supports injection of random interference (RI) and sinusoidal interference (SI) through couplers, with M8000 software controlling external sources such as the M8054A interference source or M8195A/M8196A AWGs.
How does the M8040A remote head concept improve test signal quality?
The M8040A uses remote head M8057A/B modules connected by 0.85 m cables to the pattern generator module M8045A. Each remote head contains an adjustable gain amplifier without a re-timer, allowing users to position the output closely to the device under test board. This short connection minimizes signal degradation caused by lossy channels, delivering clean PAM4 and NRZ signals with fast transitions and low intrinsic jitter directly at the test point.
What de-emphasis capabilities does the M8040A pattern generator offer?
With Option 0G4, the M8045A pattern generator provides built-in de-emphasis using a 4-tap (5-coefficient) FIR filter with both positive and negative cursors. The coefficients include two pre-cursors (c0, c1) adjustable from 0.0 to 0.40, a main cursor (c2) up to 1.0, and two post-cursors (c3, c4) up to 0.40, each with 0.01 resolution. The sum of all absolute coefficient values must not exceed 1.0, and settings apply independently to each channel for both NRZ and PAM4 modes.
What error analysis capabilities does the M8040A analyzer module provide for PAM4 signals?
The M8046A analyzer module provides true PAM4 error detection in real-time, analyzing all three thresholds (Vlow, Vmid, Vupp) simultaneously for correct symbol error measurement. It can measure error ratios down to 10^-15 or error-free, even for long PRBS 2^31-1, QPRBS13-CEI, or QPRBS31-CEI patterns. Errored symbols at levels 0, 1, 2, and 3 can be counted separately for debugging purposes. The analyzer also includes built-in equalization to re-open closed eyes and integrated clock recovery.
What Forward Error Correction encoding does the M8040A support?
With Option 0G9, the M8045A pattern generator supports FEC encoding according to IEEE 802.3cd (draft 3.1) 50GBASE-R using Reed-Solomon code RS(544,514). The scrambler uses PRBS 2^58-1, with PAM4 line coding at 26.5625 Gbaud. Users can inject pre-FEC errors (single BIP insertion) and post-FEC errors (randomly distributed FEC symbol errors with selectable amount per frame). A PAM4 pre-coder using 1/(1+D) mod4 can be switched on or off as needed.
