Keysight Technologies N5242B-423
4-port, 10 MHz - 26.5 GHz PNA-X Network Analyzer, 3.5 mm (m)
Rent or Lease
Keysight Technologies – N5242B-423
The Keysight Technologies N5242B-423 is a 4 port network analyzer which offers powerful and versatile solutions for microwave testing for requirements more than 10 GHz. The Keysight Technologies N5242B-423 is a power-packed solution for all your microwave testing needs.
N5242B-423 Product Highlights
- 10 MHz to 26.5 GHz
- 4-ports with two built-in sources
- 132 dB system and 130 dB receiver dynamic range, 100,001 points, 200 channels, 15 MHz IF bandwidth
- High output power ( 18 dBm), low harmonics (-60 dBc) and a wide power sweep range (38 dB)
- Best dynamic accuracy: 0.1 dB compression with 13 dBm input power at the receiver
- Low noise floor of -114 dBm at 10 Hz IFBW
Keysight Technologies & TRS-RenTelco
TRS-RenTelco is a proud partner of Keysight Technologies and offers a wide range of rental, purchase and leasing solutions designed specifically to meet the evolving needs of the electronic testing industry. Our close relationship with Keysight Technologies allows us to ensure we have the right Network/Impedance Analyzers solution for your job.
Renting Network/Impedance Analyzers
With TRS-RenTelco renting Network/Impedance Analyzers equipment has never been easier. Enjoy same-day shipping, lease, and finance options on our inventory of over 5000 electronic testing equipment rentals. As one of North America’s largest test equipment rental providers, it is our mission to support the endeavors of our clients no matter how big or small with reliable expertise, excellent customer service, accuracy, and speed.
Additional Information
Manufacturer Home Page | Keysight Technologies.
- Configurations
- Resources
- FAQsAI
--, 423
See Configuration Details
-
423
4-port, configurable test set, second source, source attenuators, receiver attenuators, bias tees, combiner, mechanical switches
