Rohde & Schwarz HE300

Active directional antenna

The Rohde & Schwarz HE300 is an active directional antenna. It can be used to locate transmitters and interference sources, if combined with portable receivers such as the Rohde & Schwarz PR100. The HE300 comes with 3 exchangeable sub-range antenna modules, which cover a frequency range of 20 MHz to 7.5 GHz, with an additional module HE300HF to handle frequencies from 9 kHz to 20 MHz.

When the HE300 is operating under the Active Mode, a built-in, low-noise wideband amplifier can be activated to enhance system sensitivity and the same can be bypassed in Passive Mode. The Rohde & Schwarz HE300 is both compact and lightweight, which makes it well-suited for easy handling and operation in field conditions, and has an N type male connector.

Rohde & Schwarz HE300 Usage: handheld or mounted on tripod

Some of the key features of the Rohde & Schwarz HE300 include:

  • Horizontal and vertical polarization
  • Unambiguous direction finding
  • Direction finding by orienting antenna towards maximum signal strength
  • %22Passive%22 and %22Active%22 mode create wide dynamic range
  • 3 exchangeable antenna modules

Get the Rohde & Schwarz HE300 active directional antenna for rent or for purchase from TRS-RenTelco with 24/7 customer support. Upon purchase of this equipment, we also offer a 12 months part and labor warranty. All products come calibrated to stringent standards in our 50 GHz ANSI/NCSL Z540-1 compliant laboratory by an experienced team of metrologists and technicians. Request a quote today.

Read More
  • Configurations
  • Resources
--, HE300HF
See Configuration Details
  • HE300HF

    Loop Antenna As HF Option For HE300 9 kHz To 20 MHz (Fitting Into Transport Case Of HE300)

Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
  • Battery AA

    Qty: 6
  • Battery Holder

    Qty: 2
  • Antenna Module 20 MHz - 200 MHz

    Qty: 1
  • Antenna Module 200 MHz - 500 MHz

    Qty: 1
  • Antenna Module 9 KHz - 20 MHz

    Qty: 1
  • Antenna Module 500 MHz - 7500 MHz

    Qty: 1
  • Display Unit

    Qty: 1
  • Carrycase

    Qty: 1
  • USB Drive with Software and Manuals

    Qty: 1
