Tektronix MSO44 4-BW-1000
(4) FlexChannels 1GHZ OSCOPE with 31.25M record length
Rent or Lease
Tektronix - MSO44 4-BW-1500
With the largest display and highest available channel count in its class, the 4 Series offers unprecedented insight in a bench-friendly package. And its made-for-touch user interface works exactly as you'd expect.
MSO44 4-BW-1500 Product Highlights
• 4 or 6 FlexChannel inputs
• Each FlexChannel provides 1 analog signal input or 8 digital logic inputs with TLP058 probe
• 200 MHz, 350 MHz, 500 MHz, 1 GHz or 1.5 GHz
• 6.25 GS/s on all analog/digital channels
• 31.25 or 62.5 Mpoints
• 12 bits
• Up to 16 bits in High Res mode
Tektronix & TRS-RenTelco
TRS-RenTelco is a proud partner of Tektronix and offers a wide range of rental, purchase and leasing solutions designed specifically to meet the evolving needs of the electronic testing industry. Our close relationship with Tektronix allows us to ensure we have the right Oscilloscopes solution for your job.
Renting Oscilloscopes
With TRS-RenTelco, renting Oscilloscopes equipment has never been easier. Enjoy same-day shipping, lease, and finance options on our inventory of over 5000 electronic testing equipment rentals. As one of North America’s largest test equipment rental providers, it is our mission to support the endeavors of our clients no matter how big or small with reliable expertise, excellent customer service, accuracy, and speed.
Links to Additional Information
- Configurations
- Resources
- FAQsAI
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cord Power
Qty: 1 -
Mouse Optical
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1 -
Marker Set
Qty: 1 -
MAN-TPP1000 300V CAT II and 1 GHz 10X Passive Probes
Qty: 1 -
Probe
Qty: 4
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 4-AFG, 4-RL-1, 4-SV-BW-1
See Configuration Details
-
4-AFG
Installed Option; Arbitrary Function Generator
-
4-RL-1
Installed Option; Extend record length to 62.5M/ch maximum
-
4-SV-BW-1
Installed Option; Increase Spectrum View Capture Bandwidth to 500 MHz
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Marker Set
Qty: 1 -
Case Soft
Qty: 1 -
Cord Power
Qty: 1 -
Mouse Optical
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1 -
Probe
Qty: 4
*This item has already been added to your cart. Check your cart for quantity and availability.
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the maximum bandwidth and sample rate of the Tektronix MSO44 with 1 GHz configuration?
The Tektronix MSO44 4 Series MSO offers 1 GHz bandwidth (upgradable) with a real-time sample rate of 6.25 GS/s across all analog and digital channels simultaneously. This sample rate is maintained across all four FlexChannel inputs, ensuring consistent performance whether you are using analog or digital channels, eliminating the tradeoffs found in previous-generation mixed signal oscilloscopes.
How does the FlexChannel technology work on the 4 Series MSO?
FlexChannel technology allows each of the four inputs to function as either one analog channel or eight digital logic inputs when a TLP058 logic probe is attached. You can dynamically reconfigure channels by simply adding or removing probes, enabling configurations like four analog channels, three analog plus eight digital, or two analog plus 16 digital channels. Digital channels share the same 6.25 GS/s sample rate and up to 62.5 Mpoint record length as analog channels.
What vertical resolution does the MSO44 provide for precision measurements?
The MSO44 features a 12-bit ADC that provides 16 times the vertical resolution of traditional 8-bit oscilloscopes. In High Res mode, the instrument applies a hardware-based Finite Impulse Response filter that extends vertical resolution up to 16 bits at sample rates of 125 MS/s or lower, enabling you to capture high-amplitude signals while resolving smaller signal details with minimal noise.
What record length options are available on the Tektronix 4 Series MSO44?
The MSO44 comes standard with 31.25 Mpoints of record length across all analog and digital channels. An optional upgrade extends this to 62.5 Mpoints, allowing you to capture longer duration signals while maintaining high timing resolution. This deep memory enables capturing thousands of serial packets in a single acquisition or performing extended time captures without sacrificing sample rate.
What is the waveform capture rate and why does it matter for debugging?
The 4 Series MSO44 achieves waveform capture rates exceeding 500,000 waveforms per second using Digital Phosphor technology with FastAcq. This high capture rate dramatically increases the probability of detecting infrequent glitches, runt pulses, and timing anomalies that occur randomly in digital systems. Intensity grading visually indicates how often rare transients occur relative to normal signal characteristics, making anomalies easier to spot.
Can the MSO44 perform frequency domain analysis alongside time domain measurements?
Yes, the MSO44 includes Spectrum View, a patented Tektronix technology that enables simultaneous analog and spectral views of signals with independent controls for each domain. Unlike traditional FFT implementations, Spectrum View provides intuitive spectrum analyzer controls like center frequency, span, and resolution bandwidth while maintaining optimized time-domain acquisition settings, eliminating the typical tradeoffs between frequency and time domain analysis.
What serial bus protocols can the Tektronix MSO44 decode and trigger on?
The MSO44 supports optional serial bus triggering, decode, and analysis for I2C, SPI, I3C, RS-232/422/485/UART, SPMI, CAN, CAN FD, LIN, FlexRay, SENT, PSI5, USB 2.0, eUSB2, Ethernet, Audio (I2S/LJ/RJ/TDM), MIL-STD-1553, ARINC 429, Spacewire, NRZ, SVID, and MDIO. Bus waveforms provide time-correlated decoded packet views, while bus decode tables display all packets in a tabular format for easy analysis.
What display size and resolution does the 4 Series MSO44 feature?
The MSO44 features a 13.3-inch capacitive touchscreen display with full High Definition resolution of 1,920 x 1,080 pixels, the largest and highest resolution display in its class. The display supports pinch-swipe-zoom touch interactions and offers a Stacked display mode that automatically creates separate graticules for each waveform, allowing all signals to use the full ADC range while remaining visually separated for maximum accuracy and visibility.
