Tektronix MSO64B-6-BW4000
4 Ch 4 GHz Oscope
Rent or Lease
Tektronix - MSO64B 6-BW-4000
Troubleshoot and validate high-speed designs with bandwidth that starts at 1 GHz and goes up to 10 GHz . Get accurate measurements with low noise and sample rate up to 50 GS/s . See more of your design with 6- and 8-channel models.
MSO64B 6-BW-4000 Product Highlights
• 4,6 or 8 FlexChannel inputs.
• 1, 2.5, 4, 6, 8, 10 GHz
• 50 GS/s on 2 analog channels
• 25 GS/s on 4 analog channels
• 12.5 GS/s on > 4 analog channels
• Up to 1 Gpoints on 4 channels
• Up to 500 Mpoints on > 4 channels
• 13 standard waveform types, plus arbitrary
Tektronix & TRS-RenTelco
TRS-RenTelco is a proud partner of Tektronix and offers a wide range of rental, purchase and leasing solutions designed specifically to meet the evolving needs of the electronic testing industry. Our close relationship with Tektronix allows us to ensure we have the right Oscilloscopes solution for your job.
Renting Oscilloscopes
With TRS-RenTelco, renting Oscilloscopes equipment has never been easier. Enjoy same-day shipping, lease, and finance options on our inventory of over 5000 electronic testing equipment rentals. As one of North America’s largest test equipment rental providers, it is our mission to support the endeavors of our clients no matter how big or small with reliable expertise, excellent customer service, accuracy, and speed.
Links to Additional Information
Tektronix Products from TRS-RenTelco
Other Oscilloscopes from TRS-RenTelco
- Configurations
- FAQsAI
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Accessory Pouch
Qty: 1 -
Cord Power
Qty: 1 -
Cover Front
Qty: 1 -
Probe
Qty: 4 -
Mouse Optical
Qty: 1 -
Manual Set
Qty: 1 -
Marker Set
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, sup6-dja
See Configuration Details
-
sup6-dja
License; Advanced jitter and eye analysis for 6 Series oscilloscopes; Node locked
*This item has already been added to your cart. Check your cart for quantity and availability.
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Accessory Pouch
Qty: 1 -
Cord Power
Qty: 1 -
Cover Front
Qty: 1 -
Probe
Qty: 4 -
Mouse Optical
Qty: 1 -
Manual Set
Qty: 1 -
Marker Band Set Probe Identification 2 Each Of 5 Colors
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the Tektronix MSO64B with 4 GHz bandwidth?
The Tektronix MSO64B with 4 GHz bandwidth is a mixed signal oscilloscope from the 6 Series MSO platform, offering 4 FlexChannel inputs with a 12-bit ADC and up to 25 GS/s sample rate. With the lowest input noise in its bandwidth class and the TEK061 front-end ASIC, it delivers exceptional signal fidelity for analyzing embedded systems with GHz-speed clocks and buses.
What are the sample rate and record length specifications of the 4 GHz MSO64B?
The 4 GHz MSO64B provides a 25 GS/s real-time sample rate on all analog and digital channels with 40 ps timing resolution, and an interpolated rate up to 2.5 TS/s. Standard record length is 62.5 Mpoints on all channels, with optional upgrades to 125 Mpoints and 250 Mpoints for capturing longer duration events at high resolution.
What FlexChannel and channel options does the 4 GHz MSO64B provide?
The 4 GHz MSO64B features 4 FlexChannel inputs, each configurable as a single analog channel or eight digital channels via the TLP058 logic probe. This allows up to 4 analog channels or up to 32 digital channels. Parallel buses can be up to 32 bits wide and can include a combination of analog and digital channels.
What triggering capabilities does the 4 GHz MSO64B include?
The MSO64B includes Edge, Pulse Width, Runt, Timeout, Window, Logic, Setup and Hold, Rise/Fall Time, Parallel Bus, Sequence, and Visual Trigger types. Visual Trigger enables geometric shape-based trigger qualification using an unlimited number of on-screen areas including triangles, rectangles, hexagons, and trapezoids, with Boolean logic equations for complex multi-channel trigger conditions.
What protocol decode and serial bus options are available on the 4 GHz MSO64B?
The MSO64B supports optional serial protocol triggering and analysis for I2C, SPI, RS-232/422/485/UART, SPMI, CAN, CAN FD, LIN, FlexRay, SENT, USB 2.0 (LS/FS/HS), Ethernet 10/100, Audio (I2S/LJ/RJ/TDM), MIL-STD-1553, and ARINC 429. Serial compliance testing options are available for Ethernet, USB 2.0, Automotive Ethernet, and MIPI D-PHY 1.2.
What noise performance and vertical resolution does the 4 GHz MSO64B achieve?
The 4 GHz MSO64B features the TEK061 front-end ASIC for industry-leading low noise, achieving just 97.4 microvolts RMS at 1 mV/div and 4 GHz bandwidth in High Res mode (50 ohm). The 12-bit ADC extends to 16 bits of vertical resolution in High Res mode at sample rates of 625 MS/s or below, with 200 MHz bandwidth available at maximum vertical resolution.
What display and analysis features does the 4 GHz MSO64B offer?
The MSO64B features a 15.6-inch HD (1,920 x 1,080) capacitive multi-touch display with Stacked and Overlay modes. It includes 36 automated measurements, FFT analysis, advanced waveform math, FastFrame segmented memory with a maximum trigger rate exceeding 664,000 waveforms per second, and integrated DPOJET Essentials for Time Interval Error and Phase Noise jitter analysis.
What power analysis and compliance testing features are available on the 4 GHz MSO64B?
The MSO64B offers an optional integrated power analysis package (6-PWR) for measuring power quality, switching loss, safe operating area (SOA), modulation, ripple, magnetics, efficiency, slew rate (dv/dt and di/dt), Control Loop Response (Bode Plot), and Power Supply Rejection Ratio (PSRR). Compliance test applications are available for USB 2.0, Ethernet, Automotive Ethernet, and MIPI D-PHY 1.2 standards.
