Tektronix P80318
18 GHz 100 O Differential Impedance TDR Hand Probes
Rent or Lease
Features & Benefits: * 18 GHz Bandwidth * Direct in circuit TDR testing * Reliable and repeatable resolution of impedance variations to 0.12? * Adjustable probe pitch from 0.5 mm to 4.2 mm * Probing of fully balanced differential signals without ground contact * Double cushioning design enables probe tips to maintain proper DUT contact * Protects sampling module from static damage when used with two 80A02 modules Applications: * Circuit board controlled impedance testing (TDR) * Loss tangent measurements for differential transmission lines * Failure analysis of PCB with or without components mounted * Package impedance testing (TDR)
Read More
- Configurations
- Resources
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cable Special SMA with Parallel Control Line 1 m
Qty: 2 -
Manual Instruction
Qty: 1 -
Accessory Kit Ground Wires and Cap Screw
Qty: 1 -
Strap Velcro (Set Of 2)
Qty: 1 -
Combo Alignment Tool
Qty: 1 -
Case Storage with Foam
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
User Manual - Tektronix P80318
Datasheet - Tektronix P80318
Video - Basics of Differential Probes for Oscilloscopes and their applications: a tutorial
