Tektronix RSA306B

6.2GHz USB Real Time Signal Analyzer, Type N (f)

The RSA306B uses a PC and an included Tektronix SignalVu-PC Software to provide real-time spectrum analysis, streaming capture, and deep signal analysis capabilities using the latest computing power. The RSA306B separates signal acquisition from measurement, which dramatically reduces hardware costs.

The RSA306B lets you minimize PC upgrades and IT management issues and makes computer upgrades easy.

Key Features and Performance Specifications

  • Wideband vector analysis of modern standards
  • LTE, Bluetooth, APCO 25, WLAN, and general modulation analysis
  •  Application programming interface (API) included for Microsoft Windows environments. MATLAB instrument driver for use with Instrument Control Toolbox
  • Spectrum and signal analysis measurements: 17
  • Operating temperature range: -10 degrees C to 55 degrees C
  • Full-featured spectrum analysis with options in mapping, pulse measurements, playback of recorded files, signal survey/classification
  • Gapless streaming capture records long-term events
  • 9kHz to 6.2GHz frequency range
  • Measurement range: 20 dBm to -160 dBm
  • Mil-Std 28800 Class 2 environmental, shock and vibration

If you need a signal analyzer with a higher frequency, check out the Rohde & Schwarz FSMR26, N(f) analyzer that supports up to 26GHz.

RSA306B Applications

  • Academic courses
  • Installation, maintenance, and repair jobs indoors or in the field
  • Value-driven design and manufacturing
  • Interference hunting, application programming interface

Accessories

  • 174-6796-xx: USB 3.0 locking cable (1M)
  • 063-4543-xx: SignalVu-PC software, documentation, USB key
  • 071-3323-xx: Printed safety/installation manual (English)

Optional accessories:

  • Hard and soft cases
  • Rack-mounts
  • Adaptors
  • Attenuators
  • Cables
  • Impedance converters
  • Antennas

Call us for the full range of optional accessories and model numbers.

What Are the Benefits of SignalVu-PC RF Signal Analysis Software?

You get deep analysis capabilities with SignalVu software in Tektronix high-performance spectrum analyzers. Its processing power and real-time bandwidth give you visibility into every signal. You also get real-time processing of the DPX spectrum/spectrogram enabled in the PC.

What Is the Price of the Tektronix RSA306B Signal Analyzer?

This Tektronix USB spectrum analyzer usually costs about $4,700. The price varies with seasonal discounts and offers. However, the rental rates for the RSA306B are ideal for short-term projects. Speak to us for a custom quote and a competitive rental price with the accessories you need.

Order the Tektronix RSA306B 9kHz to 6.2GHz signal analyzer online at TRS-RenTelco. If you want built-in display and data analysis software, see the Tektronix RSA5106A 6.2GHz real-time signal analyzer, Type N (f). For more options, view our complete catalog of more than 250 spectrum analyzers.

Contact us with your requirements and we will send you a custom quote. You can also fill out our contact form with the model number or call us at 800.874.7123.
