Tektronix RSA6120A

20GHz Real-Time Spectrum Analyzers, 3.5 mm (m)
Discover - Revolutionary DPX Displays Transients as Short as 24 micros with 100% probability of intercept - DPX Spectrum Processing Provides an Intuitive Understanding of Time-varying RF Signals with Color Graded Displays Based on Frequency of Occurrence Trigger - Tektronix Exclusive 40 MHz and 110 MHz Frequency Mask Triggers (FMT) Offer Easy Event-based Capture of - Transient RF Signals by Triggering on any Change in the Frequency Domain - Power Trigger Provides High Resolution Trigger on Time Domain Events - 2 External Triggers Provide Flexible Control of Triggering from ATE and Other System Equipment Capture - All Signals in Up to 110 MHz Spans are Captured into Memory - Up to 1.7 s Acquisition Length at 110 MHz Bandwidth Provides Complete Analysis Over Time Without Making Multiple Acquisitions - 6.2 GHz and 14 GHz Models Available Analyze - Extensive Time-correlated Multi-domain Displays Connect Problems in Time, Frequency, Phase and Amplitude for Quicker Understanding of Cause and Effect when Troubleshooting - All Functions are Easily Accessible via the Windows Interface. Use the Front Panel, Keyboard, Touch Screen or Mouse, Whatever you Prefer - Power Measurements and Signal Statistics Help You Characterize Components and Systems: ACLR, Multi-Carrier ACLR, Power vs. Time, CCDF - Advanced Measurement Suite (Opt. 20) - Pulse Measurements Including Rise Time, Pulse Width and Pulse-to-Pulse Phase Provide Deep Insight into Pulse Train Behavior - General Purpose Digital Modulation Analysis (Opt. 21) Provides Vector Signal Analyzer Functionality
Read More
  • Configurations
  • Resources
--, 01, 02, 05, 06, 110, 20, 200, 21
See Configuration Details
  • 01

    Internal Pre-amp (3 GHz)

  • 02

    Frequency Mask / Memory 1GB

  • 05

    500 MHz IF, Digital IQ Output

  • 06

    Removable Hard Drive

  • 110

    110 MHz Capture Bandwidth

  • 20

    Advanced Signal Analysis

  • 200

    Enhanced Dpx And Triggers For Rsa6120a Series

  • 21

    GP Modulation Analysis

Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
  • Cord Power Right Angle

    Qty: 1
  • Cover Front

    Qty: 1
  • Cable 100 Ohm 1.5 m 18 Twist Pair

    Qty: 2
  • Accessory Pouch

    Qty: 1
  • Keyboard USB

    Qty: 1
  • CD NERO CD-ROM Burning Software

    Qty: 1
  • CD Product Documentation Ver9.0

    Qty: 1
  • CD Software RSA6100A Series Ver2.1.0090

    Qty: 1
Rent or Lease

Check out first to get details on the cost.
