Anritsu MS9740B
Optical Spectrum Analyzer
Rent or Lease
Anritsu - MS9740B
The benchtop Optical Spectrum Analyzer MS9740B features wide dynamic range, high resolution, and fast sweep speeds over a wavelength range of 600 nm to 1750 nm. It supports multimode fiber input and is ideal for manufacturing and evaluating 850-nm band VCSEL modules.
As well as keeping the same functions and performance as its predecessor, the MS9740B slashes measurement processing times by up to half*1 while overcoming problems of decreased measurement sensitivity caused by increased processing speed.
Moreover, it retains optical active device (LD-Module, DF-LD, FP-LD, LED, PMD, WDM, Opt Amp, and WDM Filter) measurement menu screens for evaluating devices. It supports all-at-once measurements of key evaluation items, such as optical center wavelength, level, OSNR, spectrum width, etc., and displays these results at one screen.
MS9740B Product Highlights
• Wavelength measurement range – 600 nm to 1750 nm, covering short‑wave through L‑band applications.
• Minimum wavelength resolution – Down to 30 pm, enabling accurate measurement of closely spaced spectral components.
• Wavelength accuracy – ±20 pm in the C/L band after calibration, critical for DWDM and laser characterization.
• Dynamic range – Up to 58 dB at ±0.4 nm from the peak (70 dB at ±1 nm in high‑dynamic‑range mode).
• Optical sensitivity – As low as −90 dBm, supporting low‑power signal and noise measurements.
• Sweep speed – Typical sweep times down to 0.2–0.35 s, important for production and time‑critical measurements.
• Supported fiber types – Single‑mode and multimode fiber support, with selectable MM interface options.
• OSNR and noise analysis capabilities – Includes noise fitting, interpolation, and signal integration for accurate OSNR measurement.
• Multi‑channel WDM analysis – Supports evaluation of up to 300 WDM channels with 50 GHz and 100 GHz spacing.
• Remote control and data interfaces – Ethernet and GPIB interfaces with waveform storage and export (BMP/PNG/data files).
Anritsu & TRS-RenTelco
TRS-RenTelco is a proud partner of Anritsu and offers a wide range of rental, purchase and leasing solutions designed specifically to meet the evolving needs of the electronic testing industry. Our close relationship with Anritsu allows us to ensure we have the right Optical Test solution for your job.
Renting Optical Test
With TRS-RenTelco, renting Optical Test equipment has never been easier. Enjoy same-day shipping, lease, and finance options on our inventory of over 5000 electronic testing equipment rentals. As one of North America’s largest test equipment rental providers, it is our mission to support the endeavors of our clients no matter how big or small with reliable expertise, excellent customer service, accuracy, and speed.
Links to Additional Information
Anritsu Products from TRS-RenTelco
Other Optical Test from TRS-RenTelco
- Configurations
--, 001, 002, 040
See Configuration Details
-
001
GPIB Interface
-
002
Light Source for Wavelength Calibration
-
040
SC Connectors
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Power cord Right Angle
Qty: 1 -
Connector SC (Option 40)
Qty: 2 -
USB Drive with Software and Manuals
Qty: 1
