Associated Research 3865
5 kV AC/6kV DC Hipot Tester, Ground Continuity
The Associated Research 3865, hipot or dielectric withstand tester sets new standards for safety and ease of use in production lines. The 3865 Hypot has enhanced security features, quick data transfer features, and custom pop-up prompts displayed before each test step.
With test capabilities like AC hipot, DC hipot and ground continuity, you can achieve best practices without costly automated test systems or PC connections. The on-board data storage features on the compact 3865 hipot tester allows you to improve traceability and effortlessly transfer test result data and test settings via a convenient front panel USB.
Program your production line for increased efficiency, with direct barcode connection that lets you associate products with pre-programed test files rapidly. Make safety compliance easier than ever with the Hypot series of Hipot testers.
Associated Research 3865 - Features and Specifications:
- AC Hipot
Voltage Output = 0-5000VAC
Leakage Current Limits = 0.00-20.0mA
Output Frequency = 50/60Hz
- DC Hipot
Voltage Output = 0-6000VDC
Leakage Current Limits = 1(40)A - 7.500mA
DC Ripple equal to and less than 5% Ripple RMS at 6KVDC @ 7.5mA, Resistive Load
- Ground Continuity
Current = DC 0.1A plus/minus 0.01A, fixed
Resistance Limits = 0.0Oohms - 1.50ohms
- Quick data transfer with on-board flash drive support and local data storage
- Maximum operator protection by identifying excessive current leakage
- Increased efficiency and production throughput with the barcode scan feature; associate your DUT with the test sequence and test data
- Prompt & hold feature with custom pop-up prompts displayed between each test step
- Advanced user security with user ID and password protection for each user
- Multiple languages for testing in global environments
- Configurations
- Resources
- FAQsAI
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cable High Voltage
Qty: 1 -
Cord Power
Qty: 1 -
Lead Standard HiPot Return 5 ft
Qty: 2 -
Cable USB-A - USB-B
Qty: 1 -
Connector Interlock (installed in some units )
Qty: 1 -
USB Drive with Manuals and Software
Qty: 1 -
Connector Interlock label
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Associated Research 3865 Spec Sheet
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the Associated Research 3865?
The Associated Research 3865 is part of the Hypot® III series and serves as a high-performance AC/DC Hipot Tester equipped with ground continuity check capabilities, designed for comprehensive safety testing in production environments.
What are the key features of the 3865?
Key features include SmartGFI® for automatic operator shock protection, Remote Safety Interlock, Data Transfer via USB for easy import/export of test files and data, Direct Barcode Connection for quick product-test file association, Multi-Language support, Basic PLC relay control, Prompt & Hold for alerts and instructions between tests, Advanced User Security for customized ID and password protection, and the ability to interconnect with HYAMP® to form a complete test system.
What output rating does the 3865 provide?
The 3865 provides an output rating of 5 kVA at 20 mA AC and 6 kVA at 7.5 mA DC, suitable for a variety of test applications requiring high voltage and current.
What safety and productivity features are included in the 3865?
The model includes SmartGFI® for operator safety, a remote safety interlock feature, data transfer capabilities, barcode capability for test setup efficiency, multi-language support for global use, PLC remote for integration into automated systems, and advanced user security features.
How does the 3865 model handle ground continuity?
The 3865 includes ground continuity test capabilities with adjustable limits and auto offset to ensure the integrity of the equipment under test's ground connection.
What are the AC and DC test capabilities of the 3865?
It can perform AC Hipot testing with a range up to 5 kVA and DC Hipot testing with capabilities up to 6 kVA, offering flexibility for a wide range of test applications.
Can the 3865 store test results and settings?
Yes, the model can save up to 1500 test results on-board, facilitating traceability and quality control processes.
What are the interconnection capabilities of the 3865?
It can be quickly interconnected with the HYAMP® Series to form a comprehensive safety compliance system, streamlining the testing process.
How does the 3865 improve test traceability?
With on-board data storage and the ability to transfer test result data and settings via the front panel USB, the 3865 improves traceability and simplifies the management of test data.
What additional features enhance the testing process with the 3865?
Features like Ramp-HI® to reduce ramp time during DC Hipot testing, Charge-LO® to confirm proper DUT connection, and FailCHEK® to confirm failure detection, all contribute to a more efficient and reliable testing process.
