Keysight Technologies MSOS404A
4+16 channel 4 GHzMixed Signal Oscilloscope
Rent or Lease
Infiniium S-Series oscilloscopes incorporate innovative technology designed to deliver superior measurements.
Our new 10-bit ADC and low-noise front-end technology work together to provide up to 8 GHz performance with the industry's best signal integrity.We put these in an advanced frame with a solid state drive for fast boot-up, capacitive 15%22 display for easy touch capability, and a high-powered motherboard for fast processing.It's all compatible with a myriad of Keysight Technologies, Inc.probes and Infiniium applications.
- Configurations
- Resources
- FAQsAI
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cord Power
Qty: 1 -
Ground Lead (Pack of 5)
Qty: 1 -
Grabber Kit (Set Of 20)
Qty: 1 -
Adapter Barrel BNC(f) - BNC(f)
Qty: 1 -
Probe N2873A
Qty: 4 -
Accessory Pouch
Qty: 1 -
Mouse Optical
Qty: 1 -
Keyboard Mini USB
Qty: 1 -
Cover Front Protection
Qty: 1 -
Cable Calibration 50 Ohm BNC(m) - BNC(m)
Qty: 1 -
Cable MSO
Qty: 1 -
Adapter Probe Tip - BNC Purple
Qty: 1 -
Flying Lead Kit 17-Channel
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 200
See Configuration Details
-
200
Includes 200 Mpts/CH Memory
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cord Power
Qty: 1 -
Ground Lead (Pack of 5)
Qty: 1 -
Grabber Kit (Set Of 20)
Qty: 1 -
Adapter Barrel BNC(f) - BNC(f)
Qty: 1 -
Probe N2873A
Qty: 4 -
Accessory Pouch
Qty: 1 -
Mouse Optical
Qty: 1 -
Keyboard Mini USB
Qty: 1 -
Cover Front Protection
Qty: 1 -
Cable Calibration 50 Ohm BNC(m) - BNC(m)
Qty: 1 -
Cable MSO
Qty: 1 -
Adapter Probe Tip - BNC Purple
Qty: 1 -
Flying Lead Kit 17-Channel
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, D9010ETHC-R-B5P-001-A
See Configuration Details
-
D9010ETHC-R-B5P-001-A
Ethernet Tx Compliance Software (Ethernet, EEE)
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Adapter Barrel BNC(f) - BNC(f)
Qty: 1 -
Adapter Probe Tip - BNC Purple
Qty: 1 -
Cord Power
Qty: 1 -
Grabber Kit (Set Of 20)
Qty: 1 -
Cable Calibration 50 Ohm BNC(m) - BNC(m)
Qty: 1 -
Cable MSO
Qty: 1 -
Accessory Pouch
Qty: 1 -
Cover Front Protection
Qty: 1 -
Ground Lead (Pack of 5)
Qty: 1 -
Flying Lead Kit 17-Channel
Qty: 1 -
Probe N2873A
Qty: 4 -
Keyboard Mini USB
Qty: 1 -
Mouse Optical
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 400
See Configuration Details
-
400
Includes 400 Mpts/CH Memory
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Adapter Barrel BNC(f) - BNC(f)
Qty: 1 -
Adapter Probe Tip - BNC Purple
Qty: 1 -
Cord Power
Qty: 1 -
Grabber Kit (Set Of 20)
Qty: 1 -
Cable Calibration 50 Ohm BNC(m) - BNC(m)
Qty: 1 -
Cable MSO
Qty: 1 -
Accessory Pouch
Qty: 1 -
Cover Front Protection
Qty: 1 -
Ground Lead (Pack of 5)
Qty: 1 -
Flying Lead Kit 17-Channel
Qty: 1 -
Probe N2873A
Qty: 4 -
Keyboard Mini USB
Qty: 1 -
Mouse Optical
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the bandwidth and sample rate of the Keysight MSOS404A?
The MSOS404A offers 4 GHz analog bandwidth with a maximum sample rate of 20 GSa/s when using two channels, or 10 GSa/s across all four channels. This Infiniium S-Series oscilloscope provides excellent performance for capturing high-speed signals while maintaining the signal integrity needed for accurate measurements.
How many digital channels does the MSOS404A have?
The MSOS404A includes 16 digital channels in addition to four analog channels, making it a true mixed signal oscilloscope. The digital channels operate at 2 GSa/s with 128 Mpts of standard memory depth, allowing you to capture control signals, evaluate data buses up to 16 bits wide, and trigger across up to 20 channels simultaneously.
What is the memory depth on the MSOS404A oscilloscope?
The MSOS404A comes standard with 800 Mpts per channel when using two channels, or 400 Mpts per channel when operating all four channels. This deep memory allows you to capture long time periods while retaining fast sample rates, and the responsive architecture ensures quick update rates even with deep memory enabled.
What type of ADC does the S-Series MSOS404A use?
The MSOS404A features a 10-bit ADC with a maximum sample rate of 20 GSa/s interleaved across two channels, or 10 GSa/s across all four channels. This provides four times more vertical resolution than 8-bit oscilloscopes and supports vertical scaling as low as 2 mV/div in hardware. The high-resolution ADC works with the low-noise front end to deliver up to 16 bits of resolution in high-res mode.
Can the MSOS404A bandwidth be upgraded?
Yes, the MSOS404A supports user-installed bandwidth upgrades to higher models including 6 GHz and 8 GHz configurations. The front end incorporates a 130 nm BiCMOS IC with user-selectable analog filters that enable instant bandwidth upgrades via software license, protecting your investment as your measurement needs grow.
What is the noise floor of the MSOS404A at 1 GHz bandwidth?
The MSOS404A achieves an exceptionally low noise floor of only 90 uV at 1 mV/div with 1 GHz bandwidth. This industry-leading low noise front end is critical for viewing small signal details accurately and contributes to system ENOB values in excess of 8, delivering superior signal integrity for precision measurements.
Does the MSOS404A support protocol decode and triggering?
Yes, the MSOS404A supports protocol decode and triggering for dozens of serial buses including I2C, SPI, RS-232, USB 2.0, USB 3.0, CAN, LIN, FlexRay, PCIe, and many MIPI protocols. The digital channels can be used for protocol analysis, and optional software packages provide decode, trigger, and compliance testing capabilities for various standards.
What is the intrinsic jitter of the MSOS404A?
The MSOS404A features best-in-industry intrinsic jitter of 100 fs typical, ensuring the lowest possible contribution to jitter measurements from the oscilloscope itself. Combined with time scale accuracy of 12 ppb after calibration, this superior time base architecture enables precise jitter characterization and accurate deep memory measurements for high-speed system reliability validation.
