Keysight Technologies N4691A-00F
2-port, 26.5 GHz, MW Ecal Module, 3.5 mm (f)
The Keysight (formerly Agilent) N4691A MW electronic calibration (ECal) module makes calibration of vector network analyzers fast, easy and accurate. The RF ECal system is now easily controlled by one of two methods depending on the network analyzer. The Keysight (formerly Agilent) PNA and ENA series of network analyzers controls the module directly via the USB interface. The modules can also be controlled via an 85097B interface kit when used with an Keysight (formerly Agilent) 8753E/ES/ET or 8720D/ES/ET. (This requires a special parallel cable and firmware Rev. 7.74).
ECal is an ideal solution for calibrating network analyzers. Performing a full two-port calibration takes less than half the time and number of connections using ECal versus mechanical cal kits. Furthermore, the accuracy of the calibration is comparable between electronic and mechanical methods. Traditional mechanical calibrations require intensive operator interaction which is prone to errors. With ECal, the operator simply connects the ECal module to the network analyzer and the software controls the rest.
Read More
ECal is an ideal solution for calibrating network analyzers. Performing a full two-port calibration takes less than half the time and number of connections using ECal versus mechanical cal kits. Furthermore, the accuracy of the calibration is comparable between electronic and mechanical methods. Traditional mechanical calibrations require intensive operator interaction which is prone to errors. With ECal, the operator simply connects the ECal module to the network analyzer and the software controls the rest.
- Configurations
- Resources
--, 00F
See Configuration Details
-
00F
2 - 3.5 mm (f) connectors
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Spanner Wrench
Qty: 1 -
Wrench Torque 8 in/lb 20 mm Open End
Qty: 1 -
Wrench Torque 8 in/lb 5/16 in Open End
Qty: 1 -
Wrench 1/2 and 9/16 in
Qty: 1 -
Module Electronic Calibration
Qty: 1 -
Cable USB-A - USB-B
Qty: 1 -
Box Wooden
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Keysight Technologies N4691A-00F Spec Sheet
