Keysight Technologies N4691B-M0F

2-port, 300 kHz - 26.5 GHz Ecal module, 3.5 (m-f)

The Keysight N4691B-M0F 2-port Microwave Electronic Calibration (ECal) Modules for Vector Network Analyzers provides calibrations through 67 GHz for PNA-L and PNA network analyzers.

Controlled directly from the PNA Series network analyzers, the Keysight N4691B-M0F does not require an external PC. Connect the Keysight N4691B-M0F directly via the USB interface on the network analyzer and control your calibration from the front panel keys of the PNA Series or automatically by the user program.

The Keysight N4691B-M0F's unique S-parameter data is stored in the module's memory, which during calibration, is utilized to calculate the error terms for the network analyzer. The interface module is the interface between the parallel port on the VNA, the parallel port of the Keysight N4691B-M0F and the external power supply.

Keysight N4691B-M0F - Features and Specifications:

  • Ideal calibration technique for manufacturing
  • Replaces traditional calibration technique that employ mechanical standards
  • Uses a precision calibration traceable to the National Institute of Standards and Technology (NIST)
  • Helps reduce the chance of operator error, giving accurate calibrations
  • Reduces the wear on connectors, for lower repair costs on both the test port connectors and calibration standards
  • Faster calibration with a single connection

Get the Keysight N4691B-M0F for lease or rent from TRS-RenTelco with 365-day customer support. Contact us to request a quote today.

Read More
  • Configurations
  • Resources
--, M0F
See Configuration Details
  • M0F

    3.5mm, one female and one male connector

Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
  • Spanner Wrench

    Qty: 1
  • Wrench Torque 8 in/lb 20 mm Open End

    Qty: 1
  • Wrench Torque 8 in/lb 5/16 in Open End

    Qty: 1
  • Wrench 1/2 and 9/16 in

    Qty: 1
  • Cable USB-A - USB-B

    Qty: 1
  • Box Wooden

    Qty: 1
  • Ecal Module 300 KHz - 26. 5 GHz (1-(m) and 1-(f) Connector)

    Qty: 1
  • USB Drive with Software and Manuals

    Qty: 1
Rent or Lease

Check out first to get details on the cost.

Buy Used

In stock now. Request Quote for pricing.
