Keysight Technologies N5224B-200
2-port, 10 MHz - 43.5 GHz PNA Network Analyzer, 2.4 mm (m)
Rent or Lease
Keysight Technologies – N5224B-200
The Keysight Technologies N5224B-200, 2-port, 43.5 GHz, PNA network analyzer offers excellent performance for testing amplifiers, mixers and frequency converters. The Keysight Technologies N5224B-200’s exceptional hardware and powerful measurement applications are built to measure a broad range of devices quickly and accurately. The Keysight Technologies N5224B-200 can measure pulsed S-parameters easily using built-in pulse modulators and pulse generators.
N5224B-200 Product Highlights
- Maximum frequency: 43.5 GHz
- Dynamic range: 127 dB
- Output power: 13 dBm
- Overcome tough measurement challenges with the highest performing microwave network
- Measure the smallest uncertainty and highest stability S-parameters
- Applications that simplify setups and let you efficiently characterize active components
- Customize to the right level of performance for specific budget and measurement needs
- Multi-touch display
- Intuitive user interface
