Keysight Technologies N9914B
FieldFox RF Analyzer 6.5 GHz, Type N(f)
Rent or Lease
With the Keysight N9914B FieldFox 6.5 GHz Handheld RF Analyzer, you can:
- Make highly accurate spectrum analyzer measurements of plus/- 0.3 dB
- Capture intermittent signals with 100 MHz gap-free real-time bandwidth
- Measure all four S parameters at the same time with 115 dB system dynamic range. The N9914B is a portable signal analyzer with measuring capacities that support 5G, satellite communications, signal monitoring and electronic warfare applications. You can also use it to support over-the-air 5G NR and LTE measurements.
TRS-RenTelco can create the right configuration for your application by adding the capabilities and options you need.
Keysight (Formerly Agilent) N9914B Features and Specifications:
- Maximum frequency of 6.5 GHz
- 100 MHz of gap-free, real-time bandwidth to capture intermittent signals
- VNA system dynamic range >115 dB
- Output power source >8 dBm in some bands
- 2 built-in ports, built-in power meter
- 7.35 lb. - The lightest, all-in-one analyzer
- Maximum analysis bandwidth 100 MHz
If you are looking for a new or well-maintained used Keysight N9914B FieldFox Handheld RF Analyzer, 6.5 GHz for rent, lease or sale, contact us or request a quote today.
- Configurations
- Resources
- FAQsAI
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cord Power
Qty: 1 -
Softcase with Backpack Strap
Qty: 1 -
Cable Patch Cat5e RJ45(m) - RJ45(m) Straight
Qty: 1 -
AC Adapter
Qty: 1 -
Battery Lithium Ion 10.8 V 70 Wh 6.4 A-Hr please do not change the description this is two different batteries they look the same one is 70W 1420-0937 & 51W 1420-0908
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 210, 211, 233, 235
See Configuration Details
-
210
Vector network analyzer transmission/reflection
-
211
Vector network analyzer full 2-port S-parameters
-
233
Spectrum analyzer
-
235
Pre-amplifier
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
AC Adapter
Qty: 1 -
Battery Lithium Ion 10.8 V 70 Wh 6.4 A-Hr please do not change the description this is two different batteries they look the same one is 70W 1420-0937 & 51W 1420-0908
Qty: 1 -
Cord Power
Qty: 1 -
Cable Patch Cat5e RJ45(m) - RJ45(m) Straight
Qty: 1 -
Softcase with Backpack Strap
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Keysight Technologies FieldFox Handheld Analyzers, B-Series Data Sheet
Keysight Technologies FieldFox Handheld Analyzers, B-Series Configuration Guide
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the frequency coverage of the Keysight N9914B FieldFox analyzer?
The N9914B is a 6.5 GHz FieldFox RF analyzer with CAT and VNA frequency coverage from 30 kHz to 6.5 GHz and spectrum analyzer frequency from 9 kHz to 6.5 GHz (useable to 5 kHz). It features Type-N female test port connectors and combines cable and antenna testing, vector network analysis, and spectrum analysis capabilities in a portable handheld format.
What measurement capabilities are included in the N9914B base model?
The base N9914B includes cable and antenna analyzer functionality as standard, providing DTF measurements in dB, linear, and VSWR formats, return loss and DTF, return loss in dB, and 1-port cable loss measurements. Calibrations included are CalReady, OSL, and response calibration. Two-port insertion loss and phase information require option 210.
What VNA options are available for the N9914B FieldFox?
Option 210 adds VNA transmission/reflection capability with S21 and S11 magnitude and phase measurements, plus 2-port insertion loss in CAT mode. Option 211 adds full 2-port S-parameters (S11, S21, S22, S12) with full 2-port calibration capability. Option 010 provides VNA time domain analysis with low-pass, impulse, and band-pass modes including gating functionality.
Can the N9914B perform spectrum analysis measurements?
Yes, with option 233, the N9914B provides spectrum analysis including basic functions with four traces, different detector types, channel power, occupied bandwidth, adjacent channel power, spectrum emission mask, AM/FM tune and listen, field strength measurements, and frequency counter marker. When combined with option 210, it provides traditional tracking generator operation with swept SA coupled to swept source.
What real-time spectrum analysis capability does the N9914B offer?
Option 350 provides real-time spectrum analyzer (RTSA) functionality with a maximum real-time bandwidth of 10 MHz. This option requires spectrum analysis capability (option 233), and the preamplifier option 235 is recommended for detecting low-power elusive signals. RTSA includes trace recording and playback capabilities built into the RTSA mode by default.
Does the N9914B support over-the-air 5G NR measurements?
Yes, the N9914B supports over-the-air 5G NR measurements with option 378, which requires options 233 (spectrum analyzer), B10 (120 MHz analysis bandwidth), and 307 (GPS receiver). The preamplifier option 235 is highly recommended. For FR1 sub-6 GHz bands, no external mixer is needed since the N9914B covers up to 6.5 GHz natively.
What power measurement capabilities are available on the N9914B?
The N9914B offers three power measurement options: option 310 provides a built-in power meter requiring no external sensor, option 302 enables USB power sensor support with compatible Keysight sensors, and option 208 adds USB power sensor measurements versus frequency functionality. Option 330 enables pulse measurements when combined with option 302 and a compatible USB peak power sensor.
What interference analysis features does the N9914B support?
With option 236, the N9914B provides interference analyzer and spectrogram capabilities along with trace playback and recording. Option 312 adds a channel scanner for monitoring multiple frequency channels. Additionally, option 361 enables EMI measurements and option 358 supports EMF measurements when used with a triaxial antenna, making the N9914B effective for field-based RF interference troubleshooting.
